QSFP+ to SFP+ OS2 OM3 OM4 MPO MTP fiber optic fanout cable

Product Details

Place of Origin: Guangdong, China

Brand Name: DYS

Certification: RoHS,ISO

Model Number: MPO - LC

Document: Product Brochure PDF

Payment & Shipping Terms

Minimum Order Quantity: 10 pieces

Price: $15.00 - $125.00/pieces

Packaging Details: Antistatic bag or ascustomers' requirements.

Supply Ability: 5000 Piece/Pieces per Day

Get Best Price

Product Details

Product Description

Highlight:

Type:	Fiber Optic Cable	Use:	FTTP
Produce Name:	MPO MTP To Duplex LC Harnesses Cable	Fiber Core:	8 Core ,12 Core , 24 Core
Connector:	MTP,MPO , MTP (Elite),MPO (Elite) ,SC,LC	Insert Loss:	≤0.35dB (SM), ≤0.30 DB (MM)
Return Loss:	≥60dB (SM), ≥30 DB(MM)	Jacket Colors:	Yellow, Aqua , Erika Violet,Purple
Jacket:	Riser (OFNR), Plenum (OFNP), LSZH	3D Testing:	100%
Length:	1M ,3M, 5M Or Customized	Multi-Mode Fiber:	OM1,OM2,OM3,OM4
Single-Mode Fiber:	G652D,G655,G657A1,G657A2	No. Of Fiber:	8,12,24
Port:	Shenzhen

Type:	Fiber Optic Cable
Use:	FTTP
Produce Name:	MPO MTP To Duplex LC Harnesses Cable
Fiber Core:	8 Core ,12 Core , 24 Core
Connector:	MTP,MPO , MTP (Elite),MPO (Elite) ,SC,LC
Insert Loss:	≤0.35dB (SM), ≤0.30 DB (MM)
Return Loss:	≥60dB (SM), ≥30 DB(MM)
Jacket Colors:	Yellow, Aqua , Erika Violet,Purple
Jacket:	Riser (OFNR), Plenum (OFNP), LSZH
3D Testing:	100%
Length:	1M ,3M, 5M Or Customized
Multi-Mode Fiber:	OM1,OM2,OM3,OM4
Single-Mode Fiber:	G652D,G655,G657A1,G657A2
No. Of Fiber:	8,12,24
Port:	Shenzhen

QSFP+ to SFP+ OS2 OM3 OM4 MPO MTP fiber optic fanout cable

Product Description

①MPO/MTP Trunk Cable
②MPO/MTP Harnesses Cables
③MPO/MTP Fan out 0.9mm Patch Cords
④IP-Series MPO/MTP Assembly
⑤High Density Patch Cords
⑥MPO/MTP Loopback
⑦MT Patch Cords
⑧MPO/MTP Cassettes
⑨MPO/MTP Fiber Optic Patch Panel

IPFX(MTP/MO)

ODVA(MTP/MPO)

High Density

QSFP+ to SFP+ OS2 OM3 OM4 MPO MTP fiber optic fanout cable

MTP Breakout cable, a cost-effective alternative to time-consuming field termination, is designed for high-density fiber patching in data centers which need space saving and reduce cable management troubles. With MTP or MPO connectors , it is optimized for 10/40/100G high-density data center applications. Please note: The US Conec MTP connectors are fully compliant with the MPO standards, achieving higher performance levels when compared to generic MPO connectors.

APPLICATION

Data communication network
Optical System Access network
Storage area networking fiber channel
High density architectures

FEATURES

1. Insertion loss type available in Standard, Elite / Low Loss
2. Fiber count available in 6, 8, 12, and 24
3. MTP/MPO connector type available in Male and Female
4. Fiber type available in SM (G652D, G657A1, G657A2), MM (OM3, OM4)
5. Fanout length available in 0.5m, 1m, etc.
6. Multi-fiber connector type available in MTP, MPO with APC or PC polishing type
7. Single-fiber connector type available in LC, SC with APC or UPC polishing type
8. Factory terminated & tested with guaranteed quality
9. High density to dramatically save space

Product Parameters

Performance Level					Standard			Elite
Connector	Mode	Endface	IL(max) (dB)	RL(min) (dB)	IL(max) (dB)	RL(min) (dB)
MPO/MTP	SM	12F/APC	≤0.70	≥60	≤0.35	≥60
				24F/APC	≤0.75	≥60	≤0.35	≥60
				48F/APC	≤0.75	≥60
		MM	12F/PC	≤0.50	≥20	≤0.35	≥20
				24F/PC	≤0.50	≥20	≤0.35	≥20
				48F/PC	≤0.50	≥20
LC/SC/FC/ST	SM		≤0.30	≥60	≤0.10	≥60
	SM			UPC	≤0.20	≥50	≤0.10	≥50
		MM	PC	≤0.20	≥30	≤0.10	≥30

Note:
1.Test wavelength:SM@1310/1550nm,MM@850/1300nm;
2.Standard conformance: GR-326,GR-1435.

Mechanical Properties
Item			Criteria	Conformance
△IL After 50 Matings	MPO/MTP	≤0.3dB	GR-1435
△IL After 500 Matings	LC/SC/FC/ST	≤0.2dB	IEC 61300-2-2
Min Bend Radius (Dynamic)			20*OD (Cable Diameter)
Min Bend Radius (Static )			15*OD (Cable Diameter)

Environment Conditions
Item	Criteria	Conformance
Operation Temperature	-40~60°C	IEC 61753-1
Storage Temperature	-45~85°C	IEC 61753-1

Main Products

Fiber Optic Cable

Patch Cord&Pigtail

MPO/MTP

FTTX Cable Assembly

PLC Splitter

Fast Connector

Our Company

Shenzhen DYS Fiber Optic Technology is a leading company in developing and manufacturing advanced fiber optic products,mainly make fiber optic indoor and outdoor cable, CPRI waterproof jumper, MPO/MTP jumper , standard fiber optic jumper and PLC Splitter. DYS win the honorary title of National High-tech enterprise by Shenzhen government in 2014.

With years of experiences in the fiber optic industry, our factory is fully equipped over 3500 square meters and more than 23 non dust production lines .About 200 well-trained staff and engineers are contributing to our proud products. We have 5 production lines for fiber optic cable, 2 high standard MPO/MTP jumper assembly lines, 8 production lines for standard jumper and 8 PLC Splitter production lines.

The most advanced imported polishing equipment and testing instruments enable our products have super quality, such as Senko polishing machine, interferometer, automatic cleaning machine and OTDR ,JGR and so on.

All of our optical products are RoHS compliant and DYS also obtained ISO9001, ISO14001 certification. Our high quality products and outstanding service win the customer from all the world, DYS fiber optic is looking forward to cooperate with you.

DYS Certifications

INNOVATIVE TECHNOLOGY

We always learn new technology by investing in production facilities, engineering process control systems, and talent development to maintain our status as a leading fiber optic connection solutions.

Our Exhibitions

Packing & Delivery

Sample

Within 1-2 working days

Wholesale orders

3-7 working days according various quantities

FAQ

1. How many staff's we have?
Answer: About 200 well-trained staff and engineers.

2. When our company be established?
Answer: We started from year 2008.

3. What's our main products?
Answer: DYS dedicates to the developing, production, marketing of the Fiber Optic Cable,
Indoor/Outdoor Patch Cord, Splitter, Adapter, Attenuator, and so on.

4. What is the area of the factory?
Over 3500 square meters
More than 18 non dust productions lines in total
4 production lines for Fiber Optic Cable
2 high standard MPO/MTP Jumper assembly lines
8 production lines for standard Jumpe
4 PLC Pplitter production lines

5. What certificate we have?
Answer: ISO 9001: 2015, RoSH, CE, High and New Tech Enterprise Certficate.
